Olympus PEN Series

The Olympus PEN cameras are among the smallest cameras for standard 35 mm film in half-frame format. The size of these cameras allowed photographers to carry them practically in their pants pocket and have them ready at all times.

Despite their compact design, these cameras delivered remarkable images. The half-frame format (18 x 24) allowed for twice the number of shots per film roll.

Over the years, a total of 20 models were developed, of which the PEN Rapid EES and PEN Rapid EED models were specifically designed for Agfa-Rapid film. The other models are designed for the 35 mm format.

The Olympus Pen, the first model of this series, was produced and sold from 1959 to 1964. It was a great success and served as the foundation for future developments. Notable is the prototype that still bore the designation "Olympus - 18". The first PEN cameras were manufactured by the company Sanko Shoji, but were inspected and shipped by Olympus. From 1960, production was completely moved to Olympus.

In 1963 and 2009, Olympus released a PEN series with interchangeable lenses. In 1963, the compact PEN F SLR system was introduced, while in 2009, the E-P1 served as the starting point for a mirrorless camera system with Micro Four Thirds lens mount.

Technical Specifications

Feature Olympus PEN Olympus PEN D Olympus PEN EES Olympus PEN EE Olympus PEN EE-3
Camera Type half-frame camera half-frame camera half-frame camera half-frame camera half-frame camera
Film format 35mm 35mm 35mm 35mm 35mm
Digital Sensor No No No No No
Film Transport Manual Manual Manual Manual Manual
Film Transport Mechanism Thumbwheel Thumbwheel Thumbwheel Thumbwheel Thumbwheel
Picture Format 18 mm x 24 mm 18 mm x 24 mm 18 mm x 24 mm 18 mm x 24 mm 18 mm x 24 mm
Lens type Fixed lens Fixed lens Fixed lens Fixed lens Fixed lens
Focal Length 28 mm 32 mm 28 mm 28 mm 28 mm
Maximum Aperture f/3.5 f/1.9 f/2.8 f/3.5 f/3.5
Shutter Speeds 1/200 – 1/25 – second 1/500 – 1/8 – second 1/200 – 1/40 – second
Light Meter No Yes Yes Yes Yes
Flash PC-Flash PC-Flash PC-Flash PC-Flash Hot Shoe, PC-Flash
Focus manual manual manual Fixed focus Fixed focus
Weight 320 395 400 350 280
Size 11 x 7 x 4.2 cm 10.8 x 6.7 x 5 cm 10.8 x 6.6 x 4.7 cm 10.8 x 6.6 x 4.2 cm 11.3 x 7 x 4.4 cm
Release Date 1959 1962 1962 1961 1973
Production start 1959 1962 1962 1961 1973
Production End 1964 1968
Manufacturer Olympus Olympus Olympus Olympus Olympus
Country of Origin Japan Japan Japan Japan Japan
Age Up to 67 years Up to 64 years Up to 64 years Up to 65 years Up to 53 years
Bulb Mode Yes Yes
Production duration 5 years 6 years
