Samsung Evoca 70SE

Orange links = Amazon Ad
Can you order this camera on Amazon?
  • Brand: Samsung
  • Name: Samsung Evoca 70SE
  • Sales names: Samsung VEGA 77i
  • Type: Snapshot camera
  • Type of Film: 35mm
  • Focal length: 35 mm - 70 mm
  • Maximum aperture: f/4.5
  • Focus: Autofocus
  • Shutter speeds: 1/400 s to 1/3 s, Bulb
  • Flash / Flash connection: Built-in flash

The Samsung Evoca 70SE is a 35 mm camera. It belongs to the group of snapshot cameras with zoom function. It was marketed under the name “Samsung VEGA 77i”. The body of the camera is silver.

There is a fixed lens installed in the camera. The lens has a maximum aperture of f/4.5 and the focal length range of the zoom is 35 mm to 70 mm. The manufacturer’s name of the lens is “Schneider-Kreuznach Varioplan 35-70mm Auto Macro”. Focusing is facilitated by a built-in autofocus. The closest focusing distance is specified as 55 cm for this lens.

Measuring exposure is made easier by the built-in light meter. It is designed for an ISO range of 50 to 3200. The correct ISO value is read out by the DX code on the film cartridge and the exposure meter is set accordingly. The Samsung Evoca 70SE has an automatic exposure control. The photographer cannot select the aperture and exposure time.

There is a bulb mode for long exposures. Here, the shutter can remain open for a variable time and expose the film. For shooting in low light, there is a built-in flash, this ensures clear shots.

A special feature of the camera is the possibility of exposing the current date and time in the film. There is also a panorama function. However, this only consists of two bars in the image and does not change the viewing angle.

The camera weighs 180 grams and measures 10.9 x 3.3 x 6 cm. The camera requires a CR2 battery (eBay / Amazon*). This supplies power to the flash and LCD display, among other things.

Films for the Samsung Evoca 70SE

The Samsung Evoca 70SE is designed for 35mm film. These films are still manufactured and can be specified with almost any developing vendor. A good choice for color and black and white images is made with, for example, the Kodak Portra 160* and the Ilford HP5*.

The film transport is automatic. The photographer does not have to advance it. At the end of the film roll, the film is also automatically rewound back into the cartridge.

Technical datasheet

Technical specifications of the camera
AttributeSpecification
Type of CameraSnapshot camera
Film format35mm
Film transportAutomatic
Film transport mechanismMotor
Picture format24 mm x 36 mm
Focal length35 mm - 70 mm
Biggest aperturef/4.5
Minimum focus distance55 cm / 1.804 ft
Zoom functionYes
FocusAutofocus
Exposure times1/400 second to 1/3 second, Bulb
Bulb modeYes
Light meterYes
Supported film speedsISO 50 to 3200
Auto DXYes
Exposure modesProgram automatic
Manual exposure settingsNo
Date imprintingYes
Panorama functionYes
FlashIntegrated flash
Flash range54 cm bis 3,9 m (35 mm), 60 cm bis 2,1 m (70 mm)
Cable release threadNo
Self-timerYes
Power supply1x CR2 battery
Size10,9 x 3,3 x 6 cm
Dimensions in inches4.29 x 1.30 x 2.36 inches
Weight180 Grams
