Minolta 126 Cameras

To avoid complications for consumers when loading and unloading roll film cameras, Kodak developed a new film format in the 1960s. Inventor Hubert Nerwin developed the 126 film cartridges for Eastman Kodak. In 1964, he received a patent for it.

The 126 film format, called "Kodapak" by Kodak, uses a 35 mm wide film, spooled with a paper backing into a plastic film magazine. The exposure area is nominally 26 × 26 mm, although it is actually 29 × 28 mm, masked to about 26½ × 26½ mm. To avoid image overlap, there is an index hole for each section.

In the same decade, the Japanese Minolta introduced the first camera for this film format. Among others, a rangefinder camera for the 126 film format was also developed. Some models were sold both under the "Minolta" brand and under various private labels.

Today, unfortunately, there are no more films for these cameras.

Technical Specifications

Feature Minolta Autopak 600-X Minolta Autopak 400-X Minolta Autopak 800 Revere 3M Automatic 1064 Minolta Autopak 550 Minolta Autopak 700 REVUEmatic 500 Minolta Autopak 500
Camera Type Viewfinder camera Viewfinder camera rangefinder camera Viewfinder camera Viewfinder camera rangefinder camera Viewfinder camera Viewfinder camera
Film format 126 126 126 126 126 126 126 126
Film Transport Automatic Manual Manual Manual
Picture Format 36 mm x 24 mm
Lens type Fixed lens Fixed lens Fixed lens Fixed lens
Focal Length 38 mm 32 mm 38 mm 38 mm 38 mm 38 mm 38 mm 38 mm
Maximum Aperture f/2.8 f/8 f/2.8 f/2.8 f/2.8 f/2.8 f/2.8 f/2.8
Shutter Speeds 1/250 – 1/30 – second
Light Meter Yes Yes Yes Yes
Flash Connection for flash cubes Connection for flash cubes Connection for flash cubes Connection for flash cubes Connection for flash cubes Hot Shoe Connection for flash cubes Connection for flash cubes
Focus manual Fixed focus manual manual manual manual manual manual
Weight 250 540 320 320
Size 11.3 x 6.8 x 4.8 cm 11.8 x 7.1 x 5.7 cm 11.8 x 7.1 x 5.7 cm
Release Date 1972 1972 1969 1969 1969 1966 1966 1966
Production start 1972 1972 1969 1969 1969 1966 1966 1966
Manufacturer Minolta Minolta Minolta Minolta Minolta Minolta Revue Minolta
Country of Origin Japan Japan Japan Japan Japan
Age Up to 54 years Up to 54 years Up to 57 years Up to 57 years Up to 57 years Up to 60 years Up to 60 years Up to 60 years
Bulb Mode Yes
