Olympus 35 IV a

Orange links = Amazon Ad
Can you order this camera on Amazon?
  • Brand: Olympus
  • Name: Olympus 35 IV a
  • Predecessor: Olympus 35 IV
  • Type: Viewfinder camera
  • Type of Film: 35mm
  • Focal length: 40 mm
  • Maximum aperture: f/3.5
  • Focus: Manual
  • Shutter speeds: 1/300 s to 1 s, Bulb
  • Flash / Flash connection: PC-Flash
  • Release date: 1953
  • Age: Up to 73 years

In the golden era of photography, in July 1953 to be precise, a new star in the Olympus camera line was born – the Olympus 35 IV a. This model, which was produced until 1955, carried the legacy of its predecessors with pride while introducing some subtle but notable changes that made it an outstanding choice for photography enthusiasts of the time.

Externally, the camera retained much of the aesthetics and design of its predecessor, the Olympus 35 IV. But one noticeable change was the updating of the embossing from “MADE IN OCCUPIED JAPAN” to the modernised and politically adjusted “MADE IN JAPAN”, reflecting the burgeoning restoration of Japan as a sovereign nation.

The camera also underwent a reconfiguration in terms of flash synchronisation. While the first version retained the flash connector on the body, similar to the 35 IV, the second version moved the flash contact directly to the shutter. This was a strategic improvement that further optimised the camera’s operability.

Features

This camera model is equipped with a fixed Zuiko F.C. 1:3.5/4 cm lens that must be manually focused to obtain optimal images. It is advised to maintain a minimum distance of 90 cm from the subject to be photographed to guarantee crisp shots. The maximum aperture is f/3.5 and the focal length measures 40 mm. The smallest aperture value is f/16.

Unfortunately, the unit does not have an included light meter, so an additional device is needed for accurate metering. However, it does offer the option of shooting in Bulb mode, where the exposure time is determined by holding down the shutter button.

In addition, an external flash unit can be connected via the PC flash interface. The Olympus 35 IV a can be easily mounted on a tripod and can be operated with a cable release, with corresponding fixtures on the underside of the housing.

Weighing 530 grams and measuring 11.5 x 8 x 6.6 cm, the camera does not require batteries for operation.

Available films for the Olympus 35 IV a

The Olympus 35 IV a requires 35mm film for operation, a format that continues to play a significant role in the photographic world, which explains the continued production by some manufacturers.

Films currently available that are compatible with this camera include the Kodak ColorPlus 200* for colour images and the Ilford XP2 Super* for black and white images. These films have proven to be versatile, as confirmed by numerous reviews. Of course, there are also many other films that harmonise with this camera model.

The camera exposes an area of 24 mm x 36 mm and can accommodate about 36 exposures on a standard film (135-36). Manual film advance is an essential part of the photographic process with this 35 mm camera.

Technical datasheet

Technical specifications of the camera
AttributeSpecification
Type of CameraViewfinder camera
Film format35mm
Film transportManual
Film transport mechanismRotary knob
Picture format24 mm x 36 mm
Lens nameZuiko F.C. 1:3,5/4 cm
Focal length40 mm
Widest aperturef/3.5
Minimum focus distance90 cm / 2.952 ft
FocusManual
Lens design4 elements in 3 groups
Exposure times1/300 second to 1 second, Bulb
Bulb modeYes
Date imprintingNo
Double and/or multiple exposure functionNo
Built-in flashNo
Flash ConnectionPC-Flash
Tripod mountYes
Cable release threadYes
Self-timerNo
Connection for camera strapNo
Power supplyNot necessary
Size11,5 x 8 x 6,6 cm
Dimensions in inches4.53 x 3.15 x 2.60 inches
Weight530 Grams
Company name of the brandOlympus Optical Co., LTD.
Country of productionJapan
End of production1955
Production duration2 years

FAQ about the Olympus 35 IV a

What lens does the Olympus 35 IV a feature, and what are its key specifications?

It boasts a fixed Zuiko F.C. 1:3.5/4 cm lens, requiring manual focusing. The maximum aperture is f/3.5, and the focal length is 40mm, with a minimum aperture of f/16. A minimum focusing distance of 90cm is recommended.

Does this vintage camera include a built-in light meter, and how are exposures managed?

No, the Olympus 35 IV a lacks a built-in light meter; external metering is necessary. Exposure is controlled manually, with a bulb mode allowing for extended exposures by holding down the shutter button.

How does the Olympus 35 IV a's flash synchronization differ from its predecessor?

Unlike its predecessor, the Olympus 35 IV, the later version of the camera moved the flash connection from the body to the shutter, improving usability.

What type of film does this rangefinder camera use, and approximately how many shots can you take on a single roll?

The Olympus 35 IV a utilizes standard 35mm film. A single 135-36 roll provides space for roughly 36 exposures.

What are the physical dimensions and weight of the device; does it require batteries?

The camera measures 11.5 x 8 x 6.6 cm and weighs 530 grams. It's noteworthy that it doesn't need batteries for operation.
