Pentax 645 Series

The Pentax 645 series is a line of medium format SLR cameras from Pentax. They all expose medium format film in the 6 x 4.5 image format. The cameras in the series are equipped with a Pentax 645 lens mount and were designed for the professional market.

The first medium format camera in the series was introduced in 1984. In 2010, the Pentax 645D, a model with a digital sensor, followed. Four years later, the Pentax 645Z arrived, featuring a 51.4 megapixel CMOS sensor and a 27-point autofocus system, impressing with its relatively low introductory price for the segment.

Technical Specifications

Feature Pentax 645N II Pentax 645N Pentax 645
Camera Type single lens reflex camera single lens reflex camera single lens reflex camera
Film format 120 / Medium Format 120 / Medium Format 120 / Medium Format
Film Transport Automatic Automatic Automatic
Picture Format 56 mm x 41.5 mm 56 mm x 41.5 mm 56 mm x 41.5 mm
Lens Mount Pentax 645 A Mount Pentax 645 A Mount Pentax 645 A Mount
Lens type Interchangeable lens Interchangeable lens Interchangeable lens
Maximum Aperture - - -
Shutter Speeds 1/1000 to 30 seconds 1/1000 to 30 seconds 1/1000 to 15 seconds
Light Meter Yes Yes Yes
Exposure Compensation ± 3.3 LW ± 3 LW ± 3 LW
Flash Hot Shoe, X connector Hot Shoe, X connector Hot Shoe, X connector
Focus automatic automatic manual
Weight 1280 1280 985
Size 14.7 x 10.9 x 11.7 cm 14.7 x 10.9 x 11.7 cm 9.6 x 10.9 x 11.65 cm
Release Date 2001 1997 1984
Production start 2001 1997 1984
Manufacturer Pentax Pentax Pentax
Country of Origin Japan Japan Japan
Age Up to 25 years Up to 29 years Up to 42 years
Bulb Mode Yes Yes Yes
Power Supply 6x AA batteries 6x AA batteries 6x AA batteries
