The Samsung ECX 1 is a snapshot camera. The 35mm camera was designed by the F.A. Porsche design studio and produced by Samsung. It is the predecessor of the Samsung ECX 2. The ECX 1 was also sold under the name “Kenox FX-4”.
The 35mm camera comes with a fixed zoom lens. The manufacturer’s name of the lens is “Samsung Zoom Lens 38-140 mm Auto Macro”. The lens has a zoom range of 38 mm – 140 mm and is composed of eleven elements in nine groups. Focusing is facilitated by a built-in infrared autofocus. The closest focusing distance is 60 cm in macro mode at 38 mm.
The 35 mm camera has a built-in light meter. It can be used to set the exposure for film with a sensitivity of ISO 50 to ISO 3200. The film speed is determined via the DX code on the film cartridge. The Samsung ECX 1 has a program automatic. The photographer cannot select the aperture and exposure time. Exposure can be corrected in 0.5 EV increments (± 3EV).
The central shutter supports exposure times from 1/400 s to 1/3 s. The Bulb mode allows long exposures from 1 second to 60 seconds.
A special feature of the camera is the panorama mode. In this, the aspect ratio (13 x 36 mm) of the captured images changes. The panorama look is achieved by two inserted bars. So, in principle, you can also take a picture normally and crop the images later.
The Samsung ECX 1 comes with a built-in flash. This has a range of up to 6 meters, depending on the focal length. The recharge time is between 1 and 3 seconds.
The dimensions of the 35mm camera are 14.9 x 8.3 x 7.4 cm. At the same time, it weighs 450 grams. The power source of the 35mm camera are two CR 123A battery (eBay / Amazon*). To save power, the Samsung automatically turns off after 3 minutes of non-use.
The self-timer can take two pictures in a row if desired.
Films for the Samsung ECX 1
The Samsung ECX 1 is a film camera and is loaded with 35mm film. There is still a good selection of material for color and black and white images for this film format. A nice film for color images is the Kodak Portra 160* and for black and white images the Ilford XP2 Super*.
The development of the color negative film is done in the C-41 development process. This development process is performed by all photo labs that offer development of 35mm film. Developing a 35mm color film is possible, for example, at most drugstore chains in Germany.
Samsung ECX 1 Quartz Date
This model is identical in terms of functions. But also offers the possibility to imprint the current date on the images.
Technical datasheet
| Attribute | Specification |
|---|---|
| Type of Camera | Snapshot camera |
| Film format | 35mm |
| Film transport | Automatic |
| Film transport mechanism | Motor |
| Picture format | 24 mm x 36 mm |
| Focal length | 38 mm - 140 mm |
| Widest aperture | f/3.8 |
| Minimum focus distance | 60 cm / 1.968 ft |
| Zoom function | Yes |
| Focus | Autofocus |
| Exposure times | 1/400 second to 1/3 second, Bulb |
| Bulb mode | Yes |
| Light meter | Yes |
| Supported film speeds | ISO 50 to 3200 |
| Auto DX (Film sensitivity) | Yes |
| Exposure compensation | ± 3EV (0,5EV to) |
| Manual exposure settings | No |
| Date imprinting | Model variant |
| Panorama function | Yes |
| Flash | Integrated flash |
| Flash range | 1,2 to 6 Meter / 3.94 to 19.69 Feet |
| Cable release thread | No |
| Self-timer | Yes |
| Power supply | 2x CR123A batteries |
| Size | 14,9 x 8,3 x 7,4 cm |
| Dimensions in inches | 5.87 x 3.27 x 2.91 inches |
| Weight | 450 Grams |
| Estimated value / Used price | 52,14 Euro Estimate based on used prices of 42 offers (possibly with different scope of delivery and/or condition). As of June 15, 2026 |
| Average used price in the year 2023 | 57,22 Euro (61.70 US-Dollar) |
| Average used price in the year 2024 | 57,58 Euro (61.70 US-Dollar) |
| Average used price in the year 2025 | 50,54 Euro (54.12 US-Dollar) |
FAQ about the Samsung ECX 1
What kind of lens does the Samsung ECX 1 have?
The camera features a built-in Samsung Zoom Lens 38-140 mm Auto Macro. This means it has a zoom range and can also focus on close-up subjects thanks to its macro capabilities. The lens consists of eleven elements in nine groups.
How does the camera focus?
The Samsung ECX 1 uses infrared autofocus to help achieve sharp images. This technology aids in focusing quickly and accurately, even in less-than-ideal lighting conditions.
Does this 35mm camera have a built-in flash?
Yes, it has a built-in flash with a range up to 6 meters, depending on the focal length. The flash recharges in 1 to 3 seconds, allowing for relatively quick shooting.
What type of film does the point-and-shoot use?
The Samsung ECX 1 uses standard 35mm film. You can use color or black and white film. Many labs develop 35mm film, making it easy to get your pictures processed.
What is the special feature of the camera's panorama mode?
The panorama mode alters the aspect ratio of the image to 13 x 36 mm. This wide format is achieved by adding bars to the sides of the image; you can also crop a regular photo to achieve a similar look.
